CHINT CFS052 Motor Protector NS2-25 2.5-4A 3-Pole

CHINT CFS052 Motor Protector NS2-25 2.5-4A 3-Pole

21,50 € (Save 8,68 €)
12,82 €
Tax excluded
TVA 21% incluse : 15,51 €
CHINT NS2-25 motor protector, 3-pole, 2.5-4A overload setting, 100kA short-circuit rating.

CHINT CFS052 NS2-25 is a compact motor protection switch combining overload, short-circuit, and phase-loss protection in one unit. Suitable for direct-on-line motor starting up to 1.5 kW at 400V.

  • Overload setting: 2.5-4 A adjustable
  • 3-pole design for three-phase motors
  • Magnetic trip mechanism
  • Phase-loss protection
  • Short-circuit rating: 100 kA
  • DIN rail mountable, IP20 rating

  • Reference
    CFS052
  • ean13
    6925808307875
  • MPN
    CFS052

  • IP rating
    IP20
  • Weight
    0.31 kg
  • Nominal voltage
    690 V
  • Rated current
    4 A
  • Number of Poles
    3
  • Short-Circuit Breaking Capacity
    100 kA
  • Phase Failure Sensitive
    Yes
  • Trip Type
    Magnetic
  • Overload setting range
    2.5-4 A
  • AC-3 power at 230V
    0.75 kW
  • AC-3 power at 400V
    1.5 kW
