Structured Cabling
Cat6A backbone design for KNX IP routing and 10G PoE switches, fibre optic inter-building links for multi-building KNX networks, and patch panel integration in electrical and KNX distribution panels.
Cat6A Cabling for KNX IP Backbone and 10G PoE Switches
ISO/IEC 11801 Class EA channel parameters, PoE budget planning for Gira G1, Axis cameras and 2N IP Verso, VLAN design with IGMP snooping for KNXnet/IP multicast, cable routing separation rules and DIN-rail patch panel wiring for KNX/electrical panels.
Fibre Optic Backbone for Multi-Building KNX Networks
OM4 and OS2 fibre selection for campus KNX networks, KNX IP router placement per building, outdoor armoured loose-tube installation, fusion splicing and pre-terminated cassettes, OTDR testing per IEC 14763-3, and KNXnet/IP multicast routing across buildings with PIM-SM.
Patch Panel Integration in Electrical and KNX Distribution Panels
DIN-rail Cat6A keystone patch panels from Metz Connect, Belden and Telegärtner, T568B wiring sequence and IDC termination technique, S/FTP screen earthing without ground loops, cable routing with Velcro ties, integrated KNX and network panel layouts, and ISO 11801 labelling with panel documentation standards.
Need a certified Cat6A and KNX IP network installed to spec?
We design and install Cat6A structured cabling, DIN-rail patch panels and managed PoE switches — fully tested and documented per ISO/IEC 11801 and integrated with your KNX smart building panel.
Request a quote →
