ATTE IPP-1-21-HS Gigabit LAN + PoE Surge Protector immagini
ATTE IPP-1-21-HS Gigabit LAN + PoE Surge Protector
Prezzo:
20,37 €
Tasse escluse
IVA 21% inclusa: 24,65 €
Protect your IP cameras and network devices with ATTE IPP-1-21-HS surge protector. Supports Gigabit Ethernet and PoE. Compact and easy to install.
The ATTE IPP-1-21-HS is a surge protector designed for Gigabit Ethernet (10/100/1000 Mbps) and Power over Ethernet (PoE Passive / 802.3af / 802.3at) networks. It protects connected devices from transient overvoltages by clamping surges to a safe level.
- Gigabit Ethernet compatible – supports 10/100/1000 Mbps data rates without signal interference.
- PoE support – works with all standard PoE types including Passive, 802.3af, and 802.3at.
- High surge capacity – handles up to 30A surge current (line-line/line-ground).
- Compact design – small footprint (20 x 48 x 17 mm) fits in camera junction boxes or enclosures.
- Wide temperature range – operates from -25°C to +60°C.
- Easy installation – no external power required; simply connect inline between the network cable and the protected device.
Ideal for securing IP cameras, wireless access points, and other Ethernet devices in CCTV and network installations.
-
Marca
-
RiferimentoIPP-1-21-HS
-
In magazzino999 Articoli
-
MPNIPP-1-21-HS
-
IP ratingIP20
-
Weight0.015 kg
-
Housing materialInsulating polyethylene foil
-
Poe standardPoE Passive / 802.3af / 802.3at
-
Operating temperature range-25 ... +60 °C
-
Number of channels1
-
Connector typeShielded RJ45
-
BrandATTE
-
ModelIPP-1-21-HS
-
SKUIPP-1-21-HS
-
Product TypeSurge Protector
-
Dimensions (W x H x D)20 x 48 x 17 mm
-
Ethernet StandardGigabit Ethernet 10/100/1000 Mbps
-
Maximum Surge Current (line-line, line-ground)30 A
-
Protection Voltage (line-line)8 V
-
Protection Voltage (line-ground)400 V
-
PoE Protection Voltage65 V
